Edelbrock part #71196 Performer RPM LS3 intake manifold is designed for Gen IV engines with LS3, L92 and L76 rectangular port cylinder heads. The Performer RPM LS3 manifold is ideal for anybody looking to build a carbureted LS3 or LS2 engine with an operating range between 1,500 - 6,500 rpm. It allows the use of a carburetor on these originally computer-controlled engines, offering maximum power and a broad torque curve. It features a high-rise dual-plane design combined with a plenum that has been optimized for square-bore carburetors. This manifold includes an MSD Ignition Timing Control Module #6012, including passages for routing the coil wire harness, for a clean look. A special throttle and trans bracket that works with 700R-4, 200-4R and Turbo 350 transmissions is also included, making this an easy retro-fit into any muscle car, street rod or marine application.

Specifications:

Color	Silver
Cylinder Head Type	Rectangular Port
Description_ABR	Intake Mnfld
Description_ASM	Chevrolet:Small-Block Gen IV L76:364 (6.0L)
Description_ASM	Chevrolet:Small-Block Gen IV L76:364 (6.0L);Chevrolet:Small-Block Gen IV L77:364 (6.0L);Chevrolet:Small-Block Gen IV L92:376 (6.2L);Chevrolet:Small-Block Gen IV L94:376 (6.2L);Chevrolet:Small-Block Gen IV L99:376 (6.2L);Chevrolet:Small-Block Gen IV L9H:37
Description_ASM	Chevrolet:Small-Block Gen IV L77:364 (6.0L)
Description_ASM	Chevrolet:Small-Block Gen IV L92:376 (6.2L)
Description_ASM	Chevrolet:Small-Block Gen IV L94:376 (6.2L)
Description_ASM	Chevrolet:Small-Block Gen IV L99:376 (6.2L)
Description_ASM	Chevrolet:Small-Block Gen IV L9H:376 (6.2L)
Description_ASM	Chevrolet:Small-Block Gen IV LS3:376 (6.2L)
Description_DEF	Engine Intake Manifold
Description_DES	MANIFOLD
Description_EXT	Edelbrock Performer RPM LS3 Intake Manifold With Timing Control Module for Gen IV LS
Description_FAB	Allows Use Of Carb On Computer Controlled Engines
Description_FAB	For Race Use Only
Description_FAB	High Rise Dual-Plane Design
Description_FAB	Lightweight Casting
Description_INV	Perf RPM LS3 W/ Timing Control Module
Description_INV	Perf RPM LS3 W/Timing Control Module
Description_KEY	71196; Chevy; Chevrolet; Edelbrock; Intake Manifold; Intake; Manifold; Dual-Plane; Performer RPM; Satin
Description_LAB	Performer RPM Small Block Chevy LS3 Intake Manifold with Timing Control Module
Description_MKT	Edelbrock part #71196 Performer RPM LS3 intake manifold is designed for Gen IV engines with LS3, L92 and L76 rectangular port cylinder heads. The Performer RPM LS3 manifold is ideal for anybody looking to build a carbureted LS3 or LS2 engine with an operating range between 1,500 - 6,500 rpm. It allows the use of a carburetor on these originally computer-controlled engines, offering maximum power and a broad torque curve. It features a high-rise dual-plane design combined with a plenum that has been optimized for square-bore carburetors. This manifold includes an MSD Ignition Timing Control Module #6012, including passages for routing the coil wire harness, for a clean look. A special throttle and trans bracket that works with 700R-4, 200-4R and Turbo 350 transmissions is also included, making this an easy retro-fit into any muscle car, street rod or marine application.
Description_MKT	Edelbrock part #71196 Performer RPM LS3 intake manifold is designed for Gen IV engines with LS3, L92 and L76 rectangular port cylinder heads. The Performer RPM LS3 manifold is ideal for anybody looking to build a carbureted LS3 or LS2 engine with an operating range between 1,500 - 6,500 rpm. It allows the use of a carburetor on these originally computer-controlled engines, offering maximum power and a broad torque curve. It features a high-rise dual-plane design optimized for square-bore carburetors. This manifold kit includes an MSD Ignition Timing Control Module #6014. The ignition module has an internal MAP sensor, and works with either 24x (Gen II) or 58x (Gen IV) OE sensors to fire the Coil-on-Plug ignition system. A rotary dial offers a choice of six timing curves. More extensive programming of rev limits, nitrous retard etc. available via laptop connection. A special throttle and trans bracket that works with 700R-4, 200-4R and Turbo 350 transmissions is also included, making this an easy retro-fit into any muscle car or street rod application. Uses GM individual o-ring gaskets PN 19256623. Manifold hold down bolts included. For LS cathedral port (LS1) applications see PN 7118.
Description_SHO	{ Sellable : Yes }
Description_SHP	{ eo : 5in.}
Description_TRA	CA-3 Deg . Carb height (CH) for this manifold is measured from the valley cover flange to the carb pad
Description_TRA	Carb pad height: 5.11"
Description_TRA	Carb recommendations: Edelbrock AVS2 or Performer Series 600-800 cfm.
Description_TRA	Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Description_TRA	Manifold height: A-4.66", B-5.56"
Description_TRA	Port exit dimensions: 1.16" x 2.40"
Description_TRA	Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.
Description_TRA	Uses LS3/ L92/L76 style individual port o-ring seals GM PN19256623
Description_TRA	• Uses LS3/L92/L76 style individual port o-ring seals GM PN19256623 • Manifold height: A-4.66in.; B-5.56in. • Carb pad height: 5.11in.; CA-3deg. Carb height (CH) for this manifold is measured from the valley cover flange to the carb pad • Carb recommendations: Edelbrock AVS2 or Performer Series 600-800 cfm. • Port exit dimensions: 1.16in. x 2.40in. • Use RTV sealant to properly seal end seals; such as Edelbrock High Temp Silicone sealant # 1076; DO NOT USE END SEALS GASKETS. • Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Emission	With EGR
Emission	Without EGR
Engine Make/Size	Chevy LS3/L92
Gasket Or Seal Included	No
height	7.5
length	23.62
LTL	N
Material	Aluminum
New Or Remanufactured	New
Number of Carbs	One
Position	N/A
RPM Range	1500-6500
Usage	Street/Hi-Performance
WARNING CA Proposition 65	Yes
WARNING CA Proposition 65 Message	WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov.
weight	21.5
width	14.75
